Fence Type Semi Trailer
Request a Quote
Product description
Engine
Chassis model
Mixing capacity
Overview
| Quick Details | |||||
| Condition: | New | Transmission Type: | Manual | Emission Standard: | Euro 2 |
| Fuel Type: | Diesel | Dimensions (L x W x H) (mm): | 13000*2480*1410 | Gross Vehicle Weight: | 13000 |
| Place of Origin: | Hubei, China (Mainland) | Brand Name: | huawei | Product name: | huawin Trailer full trailer 3-axle Flatbed Semi Trailer lowest price |
| Type: | 12R22.5 | Spare tyre: | with one spare tyre | cargo body size: | 13*2.5/.*1.5M |
| Color: | Buyer's Request | ||||
Supply Ability
Supply Ability: 300 Unit/Units per Month
Packaging & Delivery
Packaging Details: Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on
Port: China main port
Lead Time:
| Quantity(Units) | 1 - 10 | >10 |
| Est. Time(day) | 30 | To be negotiated |
Specification
| DIMENSIONS | ||
| Tare Weight | 4500kg | China Factory directly sale livestock vegetable fruit bulk cargo transport stake truck fence semi trailer |
| Overall Length | 13000mm | |
| Overall Width | 2480mm | |
| Payload | 30000kg | |
| Photo for reference. Final products can be made according to exact requirements | ||
| SPECIFICATION | ||
| Chassis | Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Middle Flange 6mm,height 500mm; Bottom Flange 16mm,width 140mm. | |
| Axle | HJ Brand: 2X 13000KGS axles of Germany design | |
| Suspension | Germany design heavy duty mechanical suspension | |
| Leaf Spring | Leaf spring | |
| King Pin | JOST 2.0 Bolt-in King Pin | |
| Landing Gear | JOST Two-speed, manual operating, heavy duty landing gear | |
| Wheel Rim | 9.00-22.5 steel wheel rim, 8pcs | |
| Tire | 12R22.5 Tubeless Tire, 8pcs | |
| Spare Tire | One set of spare tire including a carrier | |
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber | |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
| Accessories | One standard tool box | |
Applications
Flat bed semi trailer for a variety of Container 20ft and 40ft
Competitive Advantage:
1) Our company produces flat semitrailer divided into flat, concave beam and tire exposed structure, beam adopts flat type or goose neck. The frame is ladder type, the beam cross-section is I-shaped, has high anti breaking strength and bearing capacity.
2) The main plane of the frame is low, which ensures the smooth transportation, and is suitable for carrying all kinds of engineering machinery, large equipment and steel.
3) Using three axis balance, double axis balance or rigid suspension, the mass balance block is arranged between the front and rear leaf springs.
4) the key parts adopt the world's top technology products
5) based on strong technical support and top level technology make the trucks with high quality and more reliable
6) competitive price, cost-effective
7) quick and efficient spare parts supply bring you more convenient
8) fast delivery time, we can arrange production according to your needs exactly and Quickly
9) professional import and export dealing procedure, make customs clearance more high efficiency
Batch export of vehicles
Ocean Shipping
