SPECIFICATION

Engine

Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model:WD615.69,Euro II
6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection
Maximum output:

336hp(247KW) at 2200 rpm
Maximum torque:

1350Nm at 1100-1600 rpm
Displacement:9.726L
Bore:126mm
Stroke:130mm

Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model:WD615.47,Euro II
6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection
Maximum output:

371hp(273KW) at 2200 rpm
Maximum torque:

1500Nm at 1100-1600 rpm
Displacement:9.726L
Bore:126mm
Stroke:130mm

Make: SINOTRUK
Disel:4-Stroke direct injection diesel engine
Engine model:D12.42,Euro II
6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection
Maximum output:

420hp(309KW) at 2000 rpm
Maximum torque:

1820Nm at 1100-1500 rpm
Displacement:11.596L
Bore:126mm
Stroke:155mm

Clutch

Single-plate dry coil-spring clutch, diameter 430mm,hydraulically operating with air assistance.

Transmission

HW19712,  12 forward, 2 reverse

HW19710,  10 forward, 2 reverse

Propeller Shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Front Axle

HF9

Steering with double T-cross section beam

Rear Axles

HC16

Pressed axle housing, central single reduction with planetary wheel reduction and with differential lock

Chassis

Frame: U-profile parallel ladder frame with section of 300��80��8mm and reinforced subframe, all cold riveted cross members

Aluminum fuel tank: 400 L capacity with locking fuel cap, fitted to the off side of the chassis

Steering

ZF power steering, model ZF8098,hydraulic steering with power assistance.  Ratio: 22.2-26.2

Braking System

Service brake: dual circuit compressed air brake. Parking brake(emergency brake):spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Tyres

12.00R20, 11pics, radial tyres

315/80R22.5, 295/80R22.5, 12R22.5

Cab

HW79Cab, double berth, all steel forward control, 55��hydraulically tiltable to the front, 2-arm windscreen
 wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped
adjustable driver��s seat and rigid adjustable co-driver��s seat, with heating and ventilating system, exterior
sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts, adjustable steering wheel, air
horn, with 4-point support fully floating suspension + shock absorbers

Electrical System

Operating voltage:24V,negative grounded

Starter:24V.7.5Kw

Alternator:3-phase,28V,1500W

Batteries:2*12V,165Ah/180Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light

Instrument

Active check central controller with indicators, with this integral instrument the daily manual checks on the

vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure

and battery charging.

Dimensions in mm

Wheel base                                                 3225+1350

Front wheel track                                            2022

Rear wheel track                                            1830

Front overhang                                              1500

Rear overhang                                               725

Approach angle(��)                                            16

Departure angel(��)                                            70

Overall length                                                6800

Overall width                                                 2496

Overall height                                                3835

Weight in kg

Dead weight                                                 9200

Front axle loading capacity                                    7000

Rear axle loading capacity                                 18000/18000

Performance

Maximum driving speed(km/h)                                 102

Fuel consumption(L/100km)                                  30-33
