Vacuum Tanker Truck
Request a Quote
Product description
Engine
Chassis model
Mixing capacity
Overview
Quick Details | |||||
Transmission Type: | Manual | Condition: | New | Emission Standard: | Euro 2 |
Fuel Type: | Diesel | Tank Volume: | 16000L |
| 7400*2496*3350 |
Place of Origin: | Hebei, China (Mainland) | Brand Name: | HOWO | Model Number: | ZZ1257N4341W |
Horsepower: | 290hp |
| 16000 | Engine: | WD615.69 |
Power: | 336 | Drive type: | 6X4 RHD/LHD Drive | Gearbox: | 19710 |
PTO: | HW50 | Front Axle: | HF7/7T | Driving Axle: | 2*ST16/16T |
Vacuum pump: | Vane pump | Suction depth: | 8 m |
| 100mm |
Supply Ability
Supply Ability: 300 Unit/Units per Month
Packaging & Delivery
Packaging Details: Nude or Waxing in Roro or bulk ship
Port: China main port
Packaging Details: Nude or Waxing in Roro or bulk ship
Port: China main port
Lead Time:30 working days after received your advance payment
Sewage Suction Truck SINOTRUK HOWO for Sanitation 16 CBM 6x4
![1667399210282542.png 1667399210282542.png](/static/upload/20221102/1667399210282542.png)
Product Description
Suction sewage truck is sanitation vehicles which is used for collecting and transporting sewage and sludge in municipal, enviromental sanitation and large property managerment company ,to avoid secondary pollution ,with vacuum suction ,pressure discharge function efficient and time saving vacuum pump,valve and others are imported products.
Specification
SINOTRUK HOWO Sewage Suction Truck for Sanitation Enterprise 16CBM 336HP | |
Chassis Model | ZZ1257N4341W |
Drive Type | 64 |
Engine | WD615.69, 336HP |
Cabin | HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat) |
Transmission | HW19710(10 forwards & 2 reverses) |
Front Axle | HF7 (1X7Tons) |
Driving Axle | ST16(2X16Tons) |
Clutch | hydraulically operating with air assistance |
Rim/ Tire | 295/80R22.5 |
Wheel base | 4300+1350(mm) |
Capacity of tank body | 16 CBM |
Diameter of suction tube | 100mm |
Suction depth | 8 m |
Vacuum pump | type: Vane pump Pumping speed: 318 m3/h Rated speed: 1300rpm |
Overall dimension | 940025003850mm |
The curb weight | 12050(Kg) |
Gross weight | 25000 kg |
Max. speed | 95km/h |
Color | White, red, green, golden and so on. |
Picture Shows
Applications
Competitive Advantage:
![sinotruk](https://www.sinotrucks.net/repository/image/Rwe3z-nOQ1S2e6D-T9aAeg.jpg)
1: Reliable quality
The truck is produced by our factory which follow ISO standard strictly and got ISO certification; each production process listed and material using in specification we follow strictly; All trucks assemble parts are produced in our workshops and we never place assemble parts order to small and private workshops.
2: Advanced function
Has sufficient vacuum to suck depth deeper than 8 mtr
Secondary protection installed on vacuum pump to forbidden sewage flow into pump
Vacuum pump driven by manual operation which is easy for clutch
The truck designed excellent appearance and with good performance
Batch export of vehicles
Ocean Shipping
IN NUDEChina main port
