Engine

model

MC07.34/340HP/Euro4

D10.38-40/380HP/Eruo4

D10.38-40/380HP/Euro4

WD615.69, 336HP Euro2

WD615.47/371/Euro2

WD615.47/371/Euro2

Displacement

6.87L

9.726L

9.726L

Cabin

H16 single sleeper, equip with air-condition, safety belt, electric lifting cabin, wind deflector.

Clutch

��430 pull-type diaphragm clutch

Transmission

HW13710/ HW19710/HW19712

12/10 front and 2 reverse, manual gearbox

SINOTRUK HW series Transmission, main and auxiliary transmission structure, main transmission with double counter shaft, auxiliary transmission with planetary reduction.

Drive Axle

HC16

SINOTRUK brand Mine with 16ton

Central reduction and hub reduction, drum brake

Speed ratio

4.42,4.8, 5.73

Front Axle

HF9

SINOTRUK brand, 9ton,

drum brake or disc brake

Frame (mm)

300X80x(8+8)/300X80x(8+8+8)

Chassis suspension

Multiple-leaf spring in front and rear

Steering

ZF power steering with hydraulic system

Tyre

11.00R20

Fuel tank

300L

Breaking system

service brake: dual-circuit air pressure brake;

parking brake: spring storage energy without air;

auxiliary brake: Engine exhaust braking.

Electronic system

voltage:24V;generator:1540W;starter:24V,7.5kw;battery:12V/165Ah,2pieces

Mixer

volume

8~12cbm

12~14cbm

Thickness

6mm

6mm

Other

ETON pump,

ETON motor,

Italy Bonfiglioli speed reducer. Speed of mixing barrel:0-16r/min

Mixing obliquity:11��

Capacity of water tank:380L

Residual rate of discharge:<0.5%

Max. dimension of hopper:980mm
